Elevate your space with the Mini Bypass Overlay Sliding Door Hardware, a sleek and versatile solution designed for seamless functionality in compact areas. Ideal for TV cabinets, pet enclosures, windows, closets, or custom furniture, this hardware system allows two or four doors to glide smoothly on a single track, maximizing space efficiency while maintaining a modern aesthetic.
Key Features
- Space-Saving Overlay Design
- Dual or Quad Configuration: Install two doors that overlap on a single track, or opt for four doors (two on each side) to create a symmetrical, space-saving solution4.
- Miniature Dimensions: With a track width of 25mm and thickness of 4mm, and rollers measuring 44mm in diameter and 24mm in width, this hardware is perfect for lightweight applications where minimalism matters.
- Heavy-Duty Performance
- Robust Load Capacity: Each door supports up to 50kg, ensuring durability for materials like wood, glass, or composite panels.
- Smooth Gliding Mechanism: Precision-engineered rollers reduce friction, enabling silent and effortless operation.
- Universal Compatibility
- Adjustable Clearance: The system requires 9cm of overhead space and a 38mm gap between the door and wall/cabinet (adjusted for door thickness).
- Door Thickness Range: Compatible with doors 20mm to 26mm thick, making it adaptable to most custom projects4.
- Easy Installation
- Comprehensive Kit: Includes pre-drilled tracks, rollers, mounting brackets, screws, and a step-by-step manual.
- Guided Support: Access detailed installation videos on our official website for hassle-free setup.
Technical Specifications
| Component | Dimensions |
|---|---|
| Track | 25mm (W) × 4mm (Thick) |
| Roller | 44mm (Dia) × 24mm (W) |
| Max Door Weight | 50kg per door |
| Door Thickness | 20–26mm |
Ideal Applications
- Home Interiors: Conceal TV cabinets, create sliding pantry doors, or partition rooms without sacrificing floor space.
- Pet Solutions: Design chic enclosures or pet gates that blend into your decor.
- Commercial Use: Optimize small offices, retail displays, or café layouts with flexible door configurations.
Installation Requirements
- Overhead Clearance: Ensure ≥9cm above the door for track mounting.
- Wall/Cabinet Gap: Calculate as 38mm – door thickness (e.g., 12mm gap for a 26mm door).
- Tools Needed: Basic drill, level, and screwdriver (included in the kit).
What’s Included?
- Pre-cut aluminum track
- High-quality rollers with bearings
- Mounting brackets and screws
- Illustrated installation manual
- Bonus: Link to online video tutorials for visual guidance.
Why Choose Our Hardware?
- Aesthetic & Functional: The slim profile and hidden hardware components ensure a clean, modern look4.
- Durability: Corrosion-resistant materials guarantee longevity in diverse environments.
- Customer Support: Reach our team for personalized advice or troubleshooting.
