Transform your space with seamless functionality and modern design.
Product Overview
The Bypass Overlay Sliding Door Hardware redefines versatility for residential and commercial spaces. Designed for single-track systems, this hardware supports configurations of two doors overlapping on one side or four doors (two per side), maximizing space efficiency while maintaining sleek aesthetics. Ideal for closets, room dividers, barn doors, or industrial partitions, our hardware combines robust engineering with user-friendly installation.
Key Features
- Space-Saving Design
- Single-track system allows doors to glide smoothly, overlapping without protruding into the room.
- Perfect for narrow spaces or areas where traditional swinging doors are impractical
- Heavy-Duty Construction
- Track Dimensions: 40mm width × 5.5mm thickness, crafted from reinforced stainless steel for unmatched durability and corrosion resistance
- Rollers: Precision-engineered with a height of 297mm, diameter of 68mm, and width of 68mm. Built with sealed ball bearings and a 55mm thickness for silent, frictionless operation, supporting up to 150kg per door
- Adjustable & Customizable
- Compatible with door thicknesses of 20mm to 40mm, ensuring flexibility for wood, metal, or composite doors.
- Door-to-wall clearance: 54mm minus door thickness, maintaining a clean, flush appearance29.
- Easy Installation
- Installation Requirements:
- Minimum 16cm overhead clearance for track mounting.
- Includes pre-drilled holes, mounting brackets, and corrosion-resistant screws (ST4.2×25, ST4.2×32)2.
- Comprehensive installation manual and accessory kit included. For visual guidance, scan the QR code or visit our official website for step-by-step video
- Installation Requirements:
Technical Specifications
| Component | Details |
|---|---|
| Track | 40mm (W) × 5.5mm (T), stainless steel |
| Rollers | 297mm (H), 68mm (Ø), 68mm (W), 55mm (T) |
| Load Capacity | 150kg per door |
| Door Thickness | 20–40mm |
| Finish | Matte black or brushed nickel (optional finishes available on request) |
Why Choose Our Hardware?
- Durability: Stainless steel components resist rust and wear, even in high-humidity environments
- Silent Operation: Rollers with silicone-embedded bearings eliminate noise during use
- Aesthetic Flexibility: Minimalist design complements modern, rustic, or industrial interiors
Ideal Applications
- Residential: Bedroom closets, pantry doors, loft partitions.
- Commercial: Office dividers, retail displays, restaurant kitchens.
- Industrial: Warehouse partitions, machinery enclosures.
FAQ
Q: Can I install this hardware on uneven floors?
A: Yes! The adjustable rollers compensate for minor floor irregularities, ensuring smooth operation10.
Q: Is professional installation required?
A: While DIY-friendly, we recommend consulting our video tutorials or hiring a technician for large or multi-door setups2.
Q: How do I maintain the rollers?
A: Periodically clean the track and apply silicone spray to reduce dust buildup. Avoid oil-based lubricants
Upgrade Your Space Today
Explore endless design possibilities with the Bypass Overlay Sliding Door Hardware. Visit https://ccjh.shop/ for inspiration, technical support, or bulk orders.
